Features
Comfortable Seat
High back seat has lumbar support and padded armrests. Red double stitching gives a high-end look with black, dark grey, and red accents.
Fully Welded Tubular Frame
Its wide front rail distributes weight for superior balance. Also supports the deck lift for easy engagement.
Parker HTJ Transaxles
They have a 12cc pump and deliver a top speed of 11mph. Filters are easily accessed from the rear for easy maintenance.
Specifications
| POWER TRAIN | |
| ENGINE | Kawasaki® FX801V |
| HORSEPOWER | 25.5 |
| ENGINE DISPLACEMENT | 52 in / 852 cc |
| POWER BRAND | N/A |
| FUEL SYSTEM | Gas |
| FUEL CAPACITY | 12.5 gal / 47.3 ltr |
| DRIVE SYSTEM | Parker® HTJ |
| BRAKE TYPE | Lever Activated Parking |
| DRIVER POSITION | Sit |
| GROUND SPEED FORWARD | 11 mph / 17.7 kph |
| GROUND SPEED REVERSE | 5 mph / 8 kph |
| WHEELS FRONT | 15.0 x 6.0 in - 6.0 in (38.1 x 15.2 cm - 15.2 cm) |
| WHEELS REAR | 24.0 x 12.0 in - 12.0 in (61.0 x 30.5 cm - 30.5 cm) |
| DECK | |
| DECK SIZE | 48 in / 121.9 cm |
| COVERAGE HOUR | 5.3 acres / 2.1 hectares |
| SPINDLE TYPE | Mechanical |
| DECK MATERIAL | 7 ga |
| DECK CONSTRUCTION | Fabricated X-Factor® 3 |
| DISCHARGE CONFIGURATION | Side |
| CUTTING HEIGHT MIN | 1 in / 2.5 cm |
| CUTTING HEIGHT MAX | 5.5 in / 14 cm |
| CUTTING WIDTH | 48 in / 121.9 cm |
| DIMENSIONS | |
| WEIGHT (ASSEMBLED) | 1235 lb / 560.1 kg |
| LENGTH | 83 In / 210.8 cm |
